TM
Model 3000M0188-01
Rev. 7/15 1-5
SPECIFICATIONS
Planter Size 4 Row 30" 6 Row 30" 8 Row 30"
Single Frame Length 11'4" (3.5M) 11'4" (3.5M) 11'4" (3.5M)
Double Frame Length 13'8" (4.2M) 13'8" (4.2M) 13'8" (4.2M)
Width 12'8" (3.9M) 17'8" (5.4M) 21'10" (6.7M)
Single Frame Weight* 2538 lb
(1151.22 kg)
3864 lb
(1752.68 kg)
4874 lb
(2210.81 kg)
Double Frame Weight* 2948 lb
(1337.19 kg)
4398 lb
(1994.90 kg)
5548 lb
(2516.53 kg)
* Base machine weights include planter frame including row markers, drive components, tires and wheels, hydraulic
cylinders, transport safety chain and Kinze pull row units (closing wheel arms less wheels) with seed hopper and lid
and dual quick adjustable down force springs.
Axle Weight Empty** N/A N/A 4950 lb
(2245.2 kg)
Tongue Weight Empty** N/A N/A 1,310 lb
(594.2 kg)
**Weight based off a typical configuration of a complete machine.
Seed Capacity 1.90 bu. (Mechanical / Hopper)
Transport/Field Tire
7.50" x 20" 8 ply rib implement tires with center groove ............ Inflate to 40 psi (275.7 kPa)
Contact Drive Tire
4.10" x 6" ...................................................................................Inflate to 50 psi (344.7 kPa)
Field Lift
Master / slave rephasing cylinders
Row Markers
Hydraulic alternating sequence valve (dual valve optional), single fold, depth bands.
TRACTOR HYDRAULIC REQUIREMENTS
Configuration Requirements Description
Base machine with mechanical
meters and row markers
1 SCV
10 gpm
(38 L/min)
#1 SCV: Planter lift and row marker auto sequencing
Base machine with mechanical
meters and row marker dual valve
conversion
2 SCV
10 gpm
(38 L/min)
#1 SCV: Planter lift
#2 SCV: Row markers with optional dual valve
