Kinze 3000 - Hydraulic Hose Information

TM
Model 3000M0188-01
Rev. 2/14 2-5
Machine Operation
HYDRAULIC HOSE INFORMATION
Part Number
A3135 A1076 A1102 A1170 A1138 A1018
Description
Hose Assembly,
" x 100"
Hose Assembly,
" x 30"
Hose Assembly,
¼" x 95"
Hose Assembly,
¼" x 90"
Hose Assembly,
¼" x 29"
Hose Assembly,
" x 40"
Product
Category
Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose
Product Form
Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly
I.D.
" (9.525 mm) " (9.525 mm) " (9.525 mm) ¼" (6.35 mm) ¼" (6.35 mm) " (9.525 mm)
O.D.
.63" (16.002 mm) .63" (16.002 mm) .63" (16.002 mm) .53" (13.462 mm) .53" (13.462 mm) .63" (16.002 mm)
Minimum Bend
Radius
2" (5.08 cm) 2" (5.08 cm) 2" (5.08 cm) 4" (10.16 cm) 4" (10.16 cm) 2" (5.08 cm)
Working
Pressure
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
3275 PSI
(22580.33 kPa)
3275 PSI
(22580.33 kPa)
3250 PSI
(22407.96 kPa)
Temperature
Range
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
Material
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Specialized
Construction
High Tensile
Steel Wire
High tensile
steel wire
High tensile
steel wire
High tensile
steel wire
High tensile
steel wire
High tensile
steel wire
Media
Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid
Application
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Part Number
A1020 A3113 A1105 A1168 A3115 A1000
Description
Hose Assembly,
" x 48"
Hose Assembly,
" x 84"
Hose Assembly,
¼" x 125"
Hose Assembly,
¼" x 120"
Hose Assembly,
" x 146"
Hose Assembly,
" x 15"
Product
Category
Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose
Product Form
Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly
I.D.
" (9.525 mm) " (9.525 mm) ¼" (6.35 mm) ¼" (6.35 mm) " (9.525 mm) " (9.525 mm)
O.D.
.63" (16.002 mm) .63" (16.002 mm) .53" (13.462 mm) .53" (13.462 mm) .63" (16.002 mm) .63" (16.002 mm)
Minimum Bend
Radius
2" (5.08 cm) 2" (5.08 cm) 4" (10.16 cm) 4" (10.16 cm) 2" (5.08 cm) 2" (5.08 cm)
Working
Pressure
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
3275 PSI
(22580.33 kPa)
3275 PSI
(22580.33 kPa)
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
Temperature
Range
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
Material
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Specialized
Construction
High tensile
steel wire
High tensile
steel wire
High tensile
steel wire
High tensile
steel wire
High tensile
steel wire
High tensile
steel wire
Media
Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid
Application
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
