Kinze 3000 - Page 20

M0188-01Model 3000
TM
Machine Operation
2-6
Rev. 2/14
Hydraulic Hose Information (Continued)
Part Number
A1086 A3119 A3175 A1019 A1079 A1090
Description
Hose Assembly,
" x 28"
Hose Assembly,
" x 36"
Hose Assembly,
" x 38"
Hose Assembly,
" x 44"
Hose Assembly,
" x 24"
Hose Assembly,
" x 162"
Product
Category
Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose
Product Form
Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly
I.D.
" (9.525 mm) " (9.525 mm) " (9.525 mm) " (9.525 mm) " (9.525 mm) " (9.525 mm)
O.D.
.63" (16.002 mm) .63" (16.002 mm) .63" (16.002 mm) .63" (16.002 mm) .63" (16.002 mm) .63" (16.002 mm)
Minimum Bend
Radius
2" (5.08 cm) 2" (5.08 cm) 2" (5.08 cm) 2" (5.08 cm) 2" (5.08 cm) 2" (5.08 cm)
Working
Pressure
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
Temperature
Range
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
Material
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Specialized
Construction
High tensile
steel wire
High tensile
steel wire
High tensile
steel wire
High tensile
steel wire
High tensile
steel wire
High tensile
steel wire
Media
Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid
Application
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Part Number
A3114 A1021 A1055 A1039
Description
Hose Assembly,
" x 156"
Hose Assembly,
" x 56"
Hose Assembly,
" x 66"
Hose Assembly,
" x 76"
Product
Category
Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose
Product Form
Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly
I.D.
" (9.525 mm) " (9.525 mm) " (9.525 mm) " (9.525 mm)
O.D.
.63" (16.002 mm) .63" (16.002 mm) .63" (16.002 mm) .63" (16.002 mm)
Minimum Bend
Radius
2" (5.08 cm) 2" (5.08 cm) 2" (5.08 cm) 2" (5.08 cm)
Working
Pressure
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
Temperature
Range
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
Material
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Specialized
Construction
High tensile
steel wire
High tensile
steel wire
High tensile
steel wire
High tensile
steel wire
Media
Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid
Application
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
