Lubrication and Maintenance
TORQUE VALUES CHART - PLATED HARDWARE
Grade 2 (No marks) Grade 5 (3 marks)
Grade 8 (6 marks)
Diameter Coarse Fine Coarse Fine Coarse Fine
¼" 50 in-lb 56 in-lb 76 in-lb 87 in-lb 9 ft-lb (12 N-m) 10 ft-lb (14 N-m)
" 8 ft-lb (11 N-m) 9 ft-lb (12 N-m) 13 ft-lb (18 N-m) 14 ft-lb (19 N-m) 18 ft-lb (24 N-m) 20 ft-lb (27 N-m)
" 15 ft-lb (20 N-m) 17 ft-lb (23 N-m) 23 ft-lb (31 N-m) 26 ft-lb (35 N-m) 33 ft-lb (45 N-m) 37 ft-lb (50 N-m)
" 25 ft-lb (34 N-m) 27 ft-lb (37 N-m) 37 ft-lb (50 N-m) 41 ft-lb (56 N-m) 52 ft-lb (71 N-m) 58 ft-lb (79 N-m)
½" 35 ft-lb (48 N-m) 40 ft-lb (54 N-m) 57 ft-lb (77 N-m) 64 ft-lb (87 N-m) 80 ft-lb (108 N-m) 90 ft-lb (122 N-m)
" 50 ft-lb (68 N-m) 60 ft-lb (81 N-m) 80 ft-lb (108 N-m) 90 ft-lb (122 N-m) 115 ft-lb (156 N-m) 130 ft-lb (176 N-m)
" 70 ft-lb (95 N-m) 80 ft-lb (108 N-m) 110 ft-lb (149 N-m) 125 ft-lb (169 N-m) 160 ft-lb (217 N-m) 180 ft-lb (244 N-m)
¾" 130 ft-lb (176 N-m) 145 ft-lb (197 N-m) 200 ft-lb (271 N-m) 220 ft-lb (298 N-m) 280 ft-lb (380 N-m) 315 ft-lb (427 N-m)
" 125 ft-lb (169 N-m) 140 ft-lb (190 N-m) 320 ft-lb (434 N-m) 350 ft-lb (475 N-m) 450 ft-lb (610 N-m) 500 ft-lb (678 N-m)
1" 190 ft-lb (258 N-m) 205 ft-lb (278 N-m) 480 ft-lb (651 N-m) 530 ft-lb (719 N-m) 675 ft-lb (915 N-m)
750 ft-lb (1017 N-m)
1" 265 ft-lb (359 N-m) 300 ft-lb (407 N-m) 600 ft-lb (814 N-m) 670 ft-lb (908 N-m) 960 ft-lb (1302 N-m) 1075 ft-lb (1458 N-m)
1¼" 375 ft-lb (508 N-m) 415 ft-lb (563 N-m) 840 ft-lb (1139 N-m) 930 ft-lb (1261 N-m) 1360 ft-lb (1844 N-m) 1500 ft-lb (2034 N-m)
1" 490 ft-lb (664 N-m) 560 ft-lb (759 N-m) 1100 ft-lb (1491 N-m) 1250 ft-lb (1695 N-m) 1780 ft-lb (2413 N-m) 2030 ft-lb (2752 N-m)
1½" 650 ft-lb (881 N-m) 730 ft-lb (990 N-m) 1450 ft-lb (1966 N-m) 1650 ft-lb (2237 N-m) 2307 ft-lb (3128 N-m) 2670 ft-lb (3620 N-m)
NOTE: Torque unplated hardware and bolts with lock nuts approximately  higher than above values. Torque
bolts lubricated prior to installation to 70% of value shown in chart.
SPECIAL TORQUE VALUES & INSTRUCTIONS
Row unit parallel linkage bushing hardware 130 ft-lb (176 Nm)
/" No till coulter spindle hardware 120 ft-lb (162 Nm)
Transport Tire Inner Budd Nuts 315 ft-lb (427 Nm)
Transport Tire Outer Budd Nuts 1075 ft-lb (1458 Nm)
Row Unit Disc Opener Blade Bolt** 110 ft-lb (149 Nm)
**Left hand side is left
hand thread.
/" - 18 Wheel Lug Nuts and Lug Bolts 200 ft-lb (271 Nm)
/" - 18 Wheel Lug Nuts and Lug Bolts 125 ft-lb (169 Nm)
" No Till Coulter Spindle Bolt - 120 Ft. Lbs.
(162.7 N-m)
Row Unit Parallel Linkage Bushing Bolts -
130 Ft. Lbs. (176.3 N-m) (See “Bushings” in
Lubrication of this section.)
