Part 1 Basic Functions 1-25
4) Pressing down Lever (C), pull out the Roll
Spool (B) from the core of the roll.
5) Loosen the Thumb Screw (D), and slide the Stopper (E) according to the width of the new roll
of media.
Tighten the Thumb Screw to fix the Stopper at the corresponding size mark.
B
C
NOTE
Align the top of triangle (F) of stopper and
the size mark (G).
F
G
A
0
E
D
To Next Page
