Chapter 4 Error Indications and Treatments
4. 1 Paper Mis-feed Errors
If the Paper Mis-feed occurs, the Paper Mis-feed Indicator on the Sub Display Panel lights to
inform you of the error.
The Sub Display Panel also indicates the Paper Mis-feed Code ( J-XX ) to let you know where the
paper is mis-fed.
Example : J-01 (Paper Mis-feed in the Roll 1)
Please check where the Paper Mis-feed has occurred referring to the following diagram.
(Greater detail on each code are on the following pages.)
Paper Mis-feed Code
Paper Mis-feed Indicator
Roll 1 Roll 2
Roll 3 Roll 4
Outer Device
(Auto Stacker,
Folder, etc.）
J-21、J-22
J-12
J-13、J-14
J-11
J-05
J-10
J-01
J-02
J-03
J-04
Front
Rear
To Next Page
