Part 1 Basic Functions 1-27
7) In case you load Roll 1 or Roll 3;
7-1) Put back the Roll Spool into the Roll Deck.
(Gear side is on the left and Lever side is on the right.)
NOTE
When you put back the Roll Spool into the Roll Deck, make sure to fit the collar of the right
side of the Roll Spool into the proper position.
No Good Good
(The collar of the Roll Spool is out of (The collar is set in the proper position.)
the proper position.)
Gear side
Front
Rear
Roll 1
Roll 2
Roll 3
Roll 4
To Next Page
