KIP 7000 - Page 34

Part 1 Basic Functions 1-28
7-2) Rotate the green knob as shown arrow and feed the leading edge of the media between
Feeding Rollers.
7-3) Close the Roll Deck.
7-4) Press the Initial Cut Key on the User Interface (UI) to cut the leading edge.
Remove the paper portion.
Knob
Front Rear
Roll 1 Roll 2
Roll 3 Roll 4
Knob
