Part 1 Basic Functions 1-30
8-2) Move the right one of Operator aid Arms
backward and then move the left one similarly.
The Roll Spool is set in the proper position
Hereby.
(Do not move both Operator aid Arms at the
same time.)
NOTE
1. “Operator aid Arm” was prepared to help the operator when you load the roll paper on the
deeper Deck. Follow the above procedure for your safety.
2. When you put back the Roll Spool into the Roll Deck, make sure to fit the collar of the
right side of the Roll Spool into the proper position.
No Good Good
(The collar of the Roll Spool is out of (The collar is set in the proper position.)
the proper position.)
1
2
To Next Page
