Part 1 Basic Functions 1-66
Clear the Paper Mis-feed using the following procedure:
1) Press the Initial Cut Key on the User Interface (UI).
2) Open the Exit Cover.
3) If it is possible to access the mis-fed paper, pull it out backward gently.
Be careful not to tear the mis-fed paper.
If it is not possible to access it, go to the next step.
WARNING
There are extremely hot parts inside the Heater Unit.
Do not touch any parts in the Heater Unit, or you will be burnt.
Also the mis-fed media can be very hot.
Be careful not to get burnt when you remove it.
Exit Cover
NOTE
The roll paper is cut hereby even if it has not been cut at the time of mis-feed.
(1) Once you make the Cutter work by pressing the Initial Cut Key on the User Interface (UI),
it will not work again even if you press the Cut key more times.
(2) In case the Cutter has worked already to cut the roll paper at the time of mis-feed,
it will not work even if you press the Initial Cut key on the User Interface (UI).
To Next Page
