Part 1 Basic Functions 1-67
4) Open the Manual Table.
5) Pull out the Upper Frame Unit to your side
holding both handles.
6) Pull up both knobs, and then push
the Top Cover to rear side.
7) Remove the mis-fed paper.
8) Close the Top Cover and the Upper Frame Unit.
9) Close the Manual Table.
Manual Table
Handles
Top Cover
Knob
To Next Page
