84
● Side clearance of piston ring
Standard(mm) Service limit(mm)
0.02-0.06 0.15
● Piston ring end clearance
Locate the piston ring into cylinder with piston top, and measure the piston end clearance.
Standard(mm) Service limit(mm)
0.15-0.25 1.0
