KITO ER2M Disassembly And Reassembly Guide

49
• Use the gear oil that comply with the specifications.
If you use different oil, a major accident such as death or serious injury may occur due to a
dropped load.
The types of oil used are different for the friction clutch and friction clutch with mechanical
brake.
* Do not top up on old oil. Use entirely new oil.
Operation check, etc.
10
After disassembly and reassembly, check the following items.
(1) Check for parts that are left unused in reassembly.
•
If any part is left, perform disassembly and reassembly again for correct assembly.
(2) Perform daily inspection.
•
For details, refer to "Daily inspection" in ER2 Series Electric Chain Hoist Owner's Manual (separate document).
(3) After checking that no error occurs with no load, perform an operation test with a rated
load.
•
For details, refer to "Regular inspection" in ER2 Series Electric Chain Hoist Owner's Manual (separate document).
Oil types and oil quantity for one unit of main body
Mandatory
Danger
Specification Code
Gear oil
amount (ml)
Oil manufacturer Oil type
Friction clutch
ER2-001H, 001IH, 003S, 003IS, 001HD, 003SD 520
KITO genuine oil KITO genuine oil
ER2-003H, 003IH, 005L, 005IL, 005S, 005IS, 003HD,
005SD, 005HD
540
ER2-010L, 010IL, 010SD, 010LD, 020C, 020IC, 020CD 620
ER2-010S, 010IS 680
ER2-015S, 015IS, 020L, 020IL, 015SD, 015LD 1300
ER2-020S, 020IS, 030S, 030IS 1900
ER2-025S, 025IS, 050S, 050IS 1900
Friction clutch
with mechanical
brake
ER2-001H, 001IH, 003S, 003IS, 001HD, 003SD 680
KITO genuine oil KITO genuine oil
ER2-005L, 005IL, 005SD 820
ER2-003H, 003IH, 005S, 005IS 900
ER2-010L, 010IL, 010SD, 010LD, 020C, 020IC, 020CD 1050
ER2-010S, 010IS 1100
ER2-015S, 015IS, 020L, 020IL, 015SD, 020LD 2000
ER2-020S, 020IS, 030S, 030IS, 030SD 2500
ER2-025S, 025IS, 050S, 050IS, 025SD, 050SD 2700
Reassembly procedure Operation check, etc.
