KITO ER2M Disassembly And Reassembly Guide

6
Name of parts
Name of parts
Load sheave
Pinion
Rotor
Motor Frame with Stator
Key B
Body
Gear case
Friction clutch
Load gear
Top hook
Electromagnetic brake
Brake cover
Fan
Fan cover
Chain Guide A
Chain Guide B
Hub spring
Packing M
Packing B
V ring
Shaft clip
Cushion rubber
Bottom yoke
Bottom hook
Motor shaft
Plate A
(for Top pin)
Oil seal
Controller cover
Packing G
Bearing holder
Top pin
Limit lever pin
Limit lever spring
Limit lever
The structure and names of parts in the
controller cover are shown on the next
page for each model.
