SYNTH TABLES
KiwiTechnics KiwiSix Upgrade
Cable requirements
The KiwiTechnics Korg PolySix Upgrade uses a standard MIDI cable
The KiwiTechnics Korg PolySix upgrade is a complete rewrite of the operating system in the Korg PolySix synthesizer.
Parameter Control via midi is now possible.
Korg© PolySix KiwiTechnics Upgrade Controls
Osc 1 Range (1) 16', 8', 4' LFO1 Wave (26) MG Destination - VCO, VCF or VCA
Osc 1 Wave (2) Sawtooth, Pulse, PWM LFO1 Delay (27) MG Delay
Osc 1 PW (3) Pulse Width Shape LFO1 Speed (28) MG Rate
Osc 1 Tune (4) Not Used Chorus/FX Rate (29) FX Rate
Osc 1 LFO Mod (5) Not Used - Use MG Destination Chorus/FX Mode (30) FX Type - Off, Chorus, Phase, Ensemble
Osc 1 ENV Mod (6) Not Used HPF (31) Not Used
Osc 1 Mode (7) Sub Osc Mode - Off, -1 Octave, -2 Octaves LPF Cutoff (32) Active
Osc 1 PWM (8) PWM Rate LPF Resonance (33) Active
Osc 1 Level (9) Not Used Filter LFO Mod (34) Not Used - Use MG Destination
Noise Level (10) Not Used Filter ENV Mod (35) VCF ENV Level - split ± 63 control
Osc 2 Range (15) Arp Range - 1,2 or 3 Octaves Filter Key Follow (36) Active
Osc 2 Wave (16) Arp Mode - Up, Down, U&D, Random EG1 ADSR (37-40) Not Used
Osc 2 PW (17) Not Used Filter Mode (41) Not Used
Osc 2 Tune (18) Not Used EG2 ADSR (42-45) Active
Osc 2 Fine Tune (19) Not Used VCA Mode (46) Select VCA - Gate or EG
Osc 2 LFO Mod (20) Not Used VCA Level (47) Active
Osc 2 ENV Mod (21) Not Used
Osc 2 Mode (22) Arp Clock Source - Int/Ext or 15 Midi Clock Types
Osc 2 PWM (23) Not Used
Osc 2 XMod Key Mode - Poly 1, Poly 2, Unison
Osc 2 Level (25) MG Osc Level
Roland© KiwiTechnics JX-3P Upgrade Notes
Random mode on the Arp is only available via midi control
Full details can be found in the KiwiTechnics Korg PolySix Upgrade manual.
