SYNTH TABLES
Roland JD-990 FX
Cable requirements
The Roland MKS-70 uses a standard MIDI cable.
Roland
©
JD990 FX Controls – Page 1
Osc 1 Range (1) Not Used LFO Wave (26) Portamento Mode
Osc 1 Wave (2) Not Used LFO Delay (27) Bend Range Up
Osc 1 PW (3) Chorus Depth LFO Speed (28) Bend Range Down
Osc 1 Tune (4) Chorus Rate Chorus/FX Rate (29) Portamento Time
Osc 1 LFO Mod (5) Chorus Delay Time Chorus/FX Mode (30) Portamento On/Off
Osc 1 ENV Mod (6) Chorus Feedback HPF (31) Solo Sync Master (Off, 4 types)
Osc 1 Mode (7) Distortion Type (7 types) LPF Cutoff (32) Phaser Depth
Osc 1 PWM (8) Chorus Level LPF Resonance (33) Phaser Resonance
Osc 1 Level (9) Distortion Drive Filter LFO Mod (34) Phaser Manual
Noise Level (10) Distortion Level Filter ENV Mod (35) Phaser Rate
Osc 2 Range (15) Solo On/Off Filter Key Follow (36) Phaser Mix
Osc 2 Wave (16) Solo Legato On/Off Filter Attack (37) Delay Tap Left
Osc 2 PW (17) Reverb Time Filter Decay (38) Delay Left Level
Osc 2 Tune (18) Reverb Early Ref Filter Sustain (39) Delay Tap Centre
Osc 2 Fine Tune (19) Reverb HF Damp Filter Release(40) Delay Center Level
Osc 2 LFO Mod (20) Reverb Pre Delay Filter Mode (41) Delay Mode
Osc 2 ENV Mod (21) Reverb Level VCA Attack (42) Delay Tap Right
Osc 2 Mode (22) Reverb Type (10 types) VCA Decay (43) Delay Right Level
Osc 2 PWM (23) Analog Feel VCA Sustain (44) Delay Feedback
Osc 2 XMod (24) Not Used VCA Release (45) Not Used
Osc 2 Level (25) Not Used VCA Mode (46) Not Used
VCA Level (47) Active
Roland
©
JD-990 FX Page 2
Osc 1 Range (1) Group A Effect Sequence (24 types) LFO Wave (26) Not Used
Osc 1 Wave (2) Group B Effect Sequence (6 types) LFO Delay (27) Not Used
Osc 1 PW (3) Not Used LFO Speed (28) Not Used
Osc 1 Tune (4) Not Used Chorus/FX Rate (29) Not Used
Osc 1 LFO Mod (5) Not Used Chorus/FX Mode (30) Not Used
Osc 1 ENV Mod (6) Not Used HPF (31) Group B Block 1 On/Off
Osc 1 Mode (7) Not Used LPF Cutoff (32) Not Used
Osc 1 PWM (8) Not Used LPF Resonance (33) Not Used
Osc 1 Level (9) Not Used Filter LFO Mod (34) Spectrum Band 1
Noise Level (10) Not Used Filter ENV Mod (35) Spectrum Band 2
Osc 2 Range (15) Group A Block 1 On/Off Filter Key Follow (36) Spectrum Band 3
Osc 2 Wave (16) Group A Block 2 On/Off Filter Attack (37) Spectrum Band 4
Osc 2 PW (17) Not Used Filter Decay (38) Spectrum Band 5
Osc 2 Tune (18) Not Used Filter Sustain (39) Spectrum Band 6
Osc 2 Fine Tune (19) Not Used Filter Release(40) Spectrum Band Width
Osc 2 LFO Mod (20) Not Used Filter Mode (41) Group B Block 2 On/Off
Osc 2 ENV Mod (21) Not Used VCA Attack (42) Not Used
Osc 2 Mode (22) Group A Block 3 On/Off VCA Decay (43) Not Used
Osc 2 PWM (23) Not Used VCA Sustain (44) Not Used
Osc 2 XMod (24) Group A Block 4 On/Off VCA Release (45) Not Used
Osc 2 Level (25) Not Used VCA Mode (46) Group B Block 3 On/Off
VCA Level (47) Not Used
Roland
©
JD990 Notes
The Roland JD-990 is a complex synth with more controls than it is possible to fit on the PE. The JD-990 has
been split up into two separate patches. One does much of the FX controls and the other the Patch Tone
Controls for Tone A-D. Each patch is made up of four separate Tones (A,B,C & D) and each of these has two
pages of controls.
It is not possible to fit all parameters into the PE layout so only those deemed the most useful for Patch editing
have been included.
www.kiwitechnics.com Patch Editor v6.0
