SYNTH TABLES
Waldorf Pulse
Cable and MIDI requirements
The Waldorf Patch uses a standard MIDI cable.
This Waldorf patch uses more controls than are available on the Patch Editor so this patch has been spread over two
pages. Menu button 3 will select the active page.
Waldorf Controls Page 1
Osc 1 Range (1) Not used LFO1 Wave (26) Sine, Triangle, Sawtooth, Pulse
Osc 1 Wave (2) Triangle, Saw, Pulse LFO1 Delay (27) Active
Osc 1 PW (3) DCO 1 Pulse Width LFO1 Speed (28) Active
Osc 1 Tune (4) DCO 1 Semitone Adjust Chorus/FX Rate (29) Portamento Time
Osc 1 LFO Mod (5) DCO 1 Pitch Mod Amount Chorus/FX Mode (30) Portamento Mode
Osc 1 ENV Mod (6) Not Used HPF (31) Filter Mod Source (Off & 15 types)
Osc 1 Mode (7) Pitch Mod Source (Off & 15 types) LPF Cutoff (32) Active
Osc 1 PWM (8) Not Used LPF Resonance (33) Active
Osc 1 Level (9) DCO 1 Level Filter LFO Mod (34) VCF Mod Amount
Noise Level (10) Noise Level Filter ENV Mod (35) VCF ENV1 Sens
Osc 2 Range (15) CV 2 Source (Off & 15 types) Filter Key Follow (36) Active
Osc 2 Wave (16) Tri, Saw, Pulse, Cross Mod Filter ADSR EG1 (37-40) Active
Osc 2 PW (17) DCO 2 Pulse Width Filter Mode (41) Not Used
Osc 2 Tune (18) DCO 2 Semitone Adjust VCA ADSR EG2 (42-45) Active
Osc 2 Fine Tune (19) DCO 2 Tune Adjust VCA Mode (46) Sustain Switch (Off, On)
Osc 2 LFO Mod (20) CV 2 Amount VCA Level (47) Active
Osc 2 ENV Mod (21) Not Used
Osc 2 Mode (22) DCO 2 Keytrack (Off, On)
Osc 2 PWM (23) DCO 2 Pulse Width Mod
Osc 2 XMod (24) DCO 2 Sync (Off, On)
Osc 2 Level (25) DCO 2 Level
Waldorf Controls Page 2
Osc 1 Range (1) Arpeggiator Active (Off, On, Hold) LFO2 Wave (26) Not Used
Osc 1 Wave (2) Arpeggiator Range (1-10 octaves) LFO2 Delay (27) LFO 2 Delay
Osc 1 PW (3) Arpeggiator Tempo LFO2 Speed (28) LFO 2 Rate
Osc 1 Tune (4) DCO 1 Tune Adjust Chorus/FX Rate (29) Not Used
Osc 1 LFO Mod (5) Not Used Chorus/FX Mode (30) Not Used
Osc 1 ENV Mod (6) Not Used HPF (31) Env 1 Trigger Mode
Osc 1 Mode (7) Arpeggiator Clock (32 settings) VCF Cutoff (32) Active
Osc 1 PWM (8) Pitch Bend Scale VCF Resonance (33) Active
Osc 1 Level (9) Not Used Filter LFO Mod (34) VCF Mod Amount
Noise Level (10) External Signal Level Filter ENV Mod (35) VCF ENV1 Sens
Osc 3 Range (15) Arpeggiator Mode (7 types) Filter Key Follow (36) Active
Osc 3 Wave (16) Tri, Saw, Pulse ADSR EG3 (37-40) Release Only - Env 1 Keyfollow Amount
Osc 3 PW (17) DCO 3 Pulse Width Filter Mode (41) Env 1 Trigger Mode
Osc 3 Tune (18) DCO 3 Semitone Adjust ADSR EG2 (42-45) Release Only - Env 2 Keyfollow Amount
Osc 3 Fine Tune (19) DCO 3 Fine Detune VCA Mode (46) Sustain Switch (Off, On)
Osc 3 LFO Mod (20) Not Used VCA Level (47) VCA Panning
Osc 3 ENV Mod (21) Not Used
Osc 3 Mode (22) Not Used
Osc 3 PWM (23) Not Used
Osc 3 XMod (24) Not Used
Osc 3 Level (25) DCO 3 Level
www.kiwitechnics.com Patch Editor v6.0
