SYNTH TABLES
Oberhiem Matrix 1000
Cable and MIDI requirements
The Oberheim Matrix 1000 uses a standard MIDI cable.
Oberheim Matrix 1000 Controls
Osc 1 Range (1) Not Used LFO1 Wave (26) Tri, Up Saw, Down Saw, Sqr, Random, Noise,
Sample Mod
Osc 1 Wave (2) Saw, Tri, Pulse, Pulse+Saw, Pulse+Tri LFO1 Delay (27) LFO 1 Rate
Osc 1 PW (3) DCO 1 Initial Pulse Width Amount LFO1 Speed (28) LFO 2 Rate
Osc 1 Tune (4) DCO 1 Tune Semitones Chorus/FX Rate (29) Not Used
Osc 1 LFO Mod (5) DCO 1 LFO Modulation Chorus/FX Mode (30) Not Used
Osc 1 ENV Mod (6) Not Used HPF (31) Not Used
Osc 1 Mode (7) DCO 1 Envelope Source EG1, EG1 inv, EG2, EG2 inv LPF Cutoff (32) Active
Osc 1 PWM (8) DCO 1 LFO2 PWM Modulation Amount LPF Resonance (33) Active
Osc 1 Level (9) Oscillator 1 <> 2 Mix Filter LFO Modulation (34) Active
Noise Level (10) Not Used Filter ENV Modulation (35) Active
Osc 2 Range (15) Not Used Filter Key Follow (36) Active
Osc 2 Wave (16) Saw, Tri, Pulse, Pulse+Saw, Pulse+Tri Filter ADSR EG1 (37-40) Active
Osc 2 PW (17) DCO 2 Initial Pulse Width Amount Filter Mode (41) Not Used
Osc 2 Tune (18) DCO 2 Tune Semitones VCA ADSR EG2 (42-45) Active
Osc 2 Fine Tune (19) DCO 2 Detune Cents VCA Mode (46) Not Used
Osc 2 LFO Mod (20) DCO 2 LFO Modulation VCA Level (47) Active
Osc 2 ENV Mod (21) Not Used
Osc 2 Mode (22) DCO 2 Envelope Source EG1, EG1 inv, EG2, EG2 inv
Osc 2 PWM (23) DCO 2 LFO2 PWM Modulation Amount
Osc 2 XMod (24) Sync On/Off
Osc 2 Level (25) Not Used
Oberheim Matrix 1000 Notes
Some Sysex commands on the Oberheim Matrix 1000 are very slow responding to sysex and it does not
respond well to large numbers of commands in rapid succession. This is especially so for the filter cutoff. When
a series of Sysex commands are sent to the M1000 the synth will stop responding and hang notes or have other
random problems until it catches up. This makes it unsuitable to control parameters in a live situation but a patch
has been provided to help set up the M1000. The parameter for Filter sustain control does not work in the M1000
and has been disabled in this patch.
www.kiwitechnics.com Patch Editor v6.0
