SYNTH TABLES
Roland JD-990 Tone
Cable requirements
The Roland JD-990 uses a standard MIDI cable.
Roland
©
JD990 Tone Controls – Page 1
Osc 1 Range (1) Wave Source (3 types) LFO Wave (26) LFO 1 Wave (8 Types)
Osc 1 Wave (2) Tone Delay Mode (5 types) LFO Delay (27) LFO 1 Delay
Osc 1 PW (3) Wave Form Low 0-127 LFO Speed (28) LFO 1 Rate
Osc 1 Tune (4) Pitch Random Chorus/FX Rate (29) LFO 1 Fade
Osc 1 LFO Mod (5) Tone Delay Time Chorus/FX Mode (30) LFO 1 Offset (3 types)
Osc 1 ENV Mod (6) FXM Depth HPF (31) Not Used
Osc 1 Mode (7) Pitch Key Follow (17 types) LPF Cutoff (32) Not Used
Osc 1 PWM (8) FXM Color LPF Resonance (33) Not Used
Osc 1 Level (9) Not Used Filter LFO Mod (34) Not Used
Noise Level (10) Not Used Filter ENV Mod (35) Not Used
Osc 2 Range (15) Tones Octave – Note works for all tones 1-4 Filter Key Follow (36) Not Used
Osc 2 Wave (16) Not Used Filter Attack (37) Pitch Envelope Time 1
Osc 2 PW (17) Not Used Filter Decay (38) Pitch Envelope Time 2
Osc 2 Tune (18) WG Pitch Course Filter Sustain (39) Pitch Envelope Sustain Level
Osc 2 Fine Tune (19) WG Pitch Fine Filter Release(40) Pitch Envelope Time 3
Osc 2 LFO Mod (20) LFO 1 Mod Filter Mode (41) Not Used
Osc 2 ENV Mod (21) Envelope Depth VCA Attack (42) Not Used
Osc 2 Mode (22) Selects Mixer Envelope Mode VCA Decay (43) Not Used
Osc 2 PWM (23) Not Used VCA Sustain (44) TVA LFO 1 Mod Level
Osc 2 XMod (24) Sync Slave Mode On/Off VCA Release (45) TVA LFO 2 Mod Level
Osc 2 Level (25) Not Used VCA Mode (46) Not Used
VCA Level (47) TVA Level
Roland
©
JD-990 FX Page 2
Osc 1 Range (1) Not Used LFO Wave (26) LFO 2 Wave (8 Types)
Osc 1 Wave (2) Not Used LFO Delay (27) LFO 2 Delay
Osc 1 PW (3) Wave Form High 128-255 LFO Speed (28) LFO 2 Rate
Osc 1 Tune (4) Not Used Chorus/FX Rate (29) LFO 2 Fade
Osc 1 LFO Mod (5) Pitch LFO 2 Mod Chorus/FX Mode (30) LFO 2 Offset (3 types)
Osc 1 ENV Mod (6) Not Used HPF (31) TVF Mode (3 types)
Osc 1 Mode (7) Pan Key Follow (15 types) LPF Cutoff (32) Filter Cutoff
Osc 1 PWM (8) Not Used LPF Resonance (33) Filter Resonance
Osc 1 Level (9) Tone Pan Filter LFO Mod (34) Filter LFO 1 Mod
Noise Level (10) Not Used Filter ENV Mod (35) Filter TVF Env Level
Osc 2 Range (15) Not Used Filter Key Follow (36) Filter Key Follow
Osc 2 Wave (16) Not Used Filter Attack (37) TVF Envelope Time 1
Osc 2 PW (17) Not Used Filter Decay (38) TVF Envelope Time 2
Osc 2 Tune (18) Not Used Filter Sustain (39) TVF Envelope Sustain Level
Osc 2 Fine Tune (19) Not Used Filter Release(40) TVF Envelope Time 4
Osc 2 LFO Mod (20) Filter LFO 2 Mod Filter Mode (41) Not Used
Osc 2 ENV Mod (21) Not Used VCA Attack (42) TVA Envelope Time 1
Osc 2 Mode (22) Not Used VCA Decay (43) TVA Envelope Time 2
Osc 2 PWM (23) Not Used VCA Sustain (44) TVA Envelope Sustain Level
Osc 2 XMod (24) Not Used VCA Release (45) TVA Envelope Time 4
Osc 2 Level (25) Not Used VCA Mode (46) Not Used
VCA Level (47) Not Used
Roland
©
JD990 Notes
The Roland JD-990 is a complex synth with more controls than it is possible to fit on the PE. The JD-990 has
been split up into two separate patches. One does much of the FX controls and the other the Patch Tone
Controls for Tone A-D. Each patch is made up of four separate Tones (A,B,C & D) and each of these has two
pages of controls.
It is not possible to fit all parameters into the PE layout so only those deemed the most useful for Patch editing
have been included.
www.kiwitechnics.com Patch Editor v6.0
