SYNTH TABLES
Korg M1
Cable and MIDI requirements
The Korg M1 uses a standard MIDI cable, The M1 must be placed in Edit Mode on the front
panel.
KORG
©
M1 Controls Pg1 - Single Mode
Osc 1 Range (1) 16', 8', 4' LFO1 Wave (26) VDF MG Wave Tri/Up Saw/Dn Saw/Sqr
Osc 1 Wave (2) Not Used - Wave selected using the PW slider LFO1 Delay (27) VDF MG Delay
Osc 1 PW (3) Wave types internal & cartridge LFO1 Speed (28) VDF MG Rate
Osc 1 Tune (4) Not Used Chorus/FX Rate (29) Effect 2 Type
Osc 1 LFO Mod (5) Pitch MG Intensity Chorus/FX Mode (30) Effect 1 On/Off
Osc 1 ENV Mod (6) Not Used HPF (31) Not Used
Osc 1 Mode (7) Voice Mode Single/Double/Drum VDF Cutoff (32) Active
Osc 1 PWM (8) Not Used LPF Resonance (33) Not Used
Osc 1 Level (9) DCO Level Filter LFO Modulation (34) VDF MG Intensity
Noise Level (10) Not Used Filter ENV Modulation (35) VDF EG Intensity
Osc 2 Range (15) Not Used Filter Key Follow (36) VDF Key Follow Amount
Osc 2 Wave (16) DCO MG Wave Tri/Up Saw/Dn Saw/Sqr Filter ADSR EG1 (37-40) A/D/S/R Only
Osc 2 PW (17) DCO MG Delay Filter Mode (41) Not Used
Osc 2 Tune (18) Not Used VDA ADSR EG2 (42-45) A/D/S/R Only
Osc 2 Fine Tune (19) Not Used VCA Mode (46) Not Used
Osc 2 LFO Mod (20) DCO MG Rate VCA Level (47) Not Used
Osc 2 ENV Mod (21) Not Used
Osc 2 Mode (22) DCO Hold On/Off
Osc 2 PWM (23) Effect 1 Type
Osc 2 XMod (24) DCO Mono/Poly
Osc 2 Level (25) Not Used
KORG
©
M1 Controls Pg2 - Double Mode
Osc 1 Range (1) DCO 1 16', 8', 4' LFO1 Wave (26) VDF MG Wave Tri/Up Saw/Dn Saw/Sqr
Osc 1 Wave (2) Not Used - DCO 1 Wave selected using the PW slider LFO1 Delay (27) VDF MG Delay
Osc 1 PW (3) Wave types internal & cartridge LFO1 Speed (28) VDF MG Rate
Osc 1 Tune (4) Not Used Chorus/FX Rate (29) Effect 2 Type
Osc 1 LFO Mod (5) Pitch MG Intensity Chorus/FX Mode (30) Effect 2 On/Off
Osc 1 ENV Mod (6) Not Used HPF (31) Not Used
Osc 1 Mode (7) Voice Mode Single/Double/Drum VDF Cutoff (32) Active
Osc 1 PWM (8) Not Used LPF Resonance (33) Not Used
Osc 1 Level (9) DCO 1 Level Filter LFO Modulation (34) VDF MG Intensity
Noise Level (10) Not Used Filter ENV Modulation (35) VDF EG Intensity
Osc 2 Range (15) DCO 1 16', 8', 4' Filter Key Follow (36) VDF Key Follow Amount
Osc 2 Wave (16) Not Used - DCO 2 Wave selected using the PW slider Filter ADSR EG1 (37-40) A/D/S/R Only
Osc 2 PW (17) Wave types internal & cartridge Filter Mode (41) Not Used
Osc 2 Tune (18) DCO 2 Tune VDA ADSR EG2 (42-45) A/D/S/R Only
Osc 2 Fine Tune (19) DCO 2 Detune VCA Mode (46) Not Used
Osc 2 LFO Mod (20) Not Used VCA Level (47) Not Used
Osc 2 ENV Mod (21) Not Used
Osc 2 Mode (22) DCO Hold On/Off
Osc 2 PWM (23) Not Used
Osc 2 XMod (24) DCO Mono/Poly
Osc 2 Level (25) DCO 2 Level
Korg M1 Notes
The M1 uses an unusual menu system which alters depending on the mode the M1 is in. The same command
sent to the M1 in Single Mode will have a completely different action in Double Mode or Drum Mode. The PE will
needs to be matched to the mode of the M1 to get useful results. The M1 also need to be placed into edit mode
on the front panel before editing is possible.
There are a large number of parameters that are not practical to edit from the PE and these must be done from
the M1. The PE tries to cover the most useful.
The oscillator wave forms are to numerous to be placed on the waveform button so these have been placed on
the PW slider. The lowest numbers select internal waves and the higher numbers select cartridge waves if a
cartridge is present.
The Envelopes in the M1 use extra controls. In addition to Attack, Decay, Sustain and Release there are break
level and slope controls. The Patch Editor only controls the A/D/S/R sections.
www.kiwitechnics.com Patch Editor v6.0
