SYNTH TABLES

Sequential Circuits Six-trak and Max

Cable and MIDI requirements

The SC Six-Trak uses a standard MIDI cable.

Sequential Circuits Six-Trak Controls

Osc 1 Range (1) Not Used LFO1 Wave (26) Triangle, Square

Osc 1 Wave (2) Not Used LFO1 Delay (27) Not Used

Osc 1 PW (3) Oscillator Glide Rate LFO1 Speed (28) Active

Osc 1 Tune (4) Not Used Chorus/FX Rate (29) Not Used

Osc 1 LFO Mod (5) Not Used Chorus/FX Mode (30) Not Used

Osc 1 ENV Mod (6) Not Used HPF (31) Not Used

Osc 1 Mode (7) Not Used LPF Cutoff (32) Active

Osc 1 PWM (8) Not Used LPF Resonance (33) Active

Osc 1 Level (9) Oscillator / Noise Mix Filter LFO Modulation (34) Active

Noise Level (10) Not Used Filter ENV Modulation (35) Active

Osc 2 Range (15) Not Used (Uses Tune control for Range) Filter Key Follow (36) Active (off / half / full)

Osc 2 Wave (16) Sawtooth, Triangle & Pulse in any selection Filter ADSR EG1 (37-40) Active

Osc 2 PW (17) Active Filter Mode (41) Filter Envelope Polarity

Osc 2 Tune (18) Coarse Tune VCA ADSR EG2 (42-45) Active

Osc 2 Fine Tune (19) Fine Tune VCA Mode (46) Not Used

Osc 2 LFO Mod (20) LFO Program Amount VCA Level (47) Active

Osc 2 ENV Mod (21) Env Modulation

Osc 2 Mode (22) Pulse LFO Modulation On/Off

Osc 2 PWM (23) Filter/Osc Tri Modulation

Osc 2 XMod (24) Oscillator Env Normal / Inverse

Osc 2 Level (25) Not Used

Sequential Circuits Sixtrak Notes

The Sequential Circuits Sixtrak uses a Curtis CEM3394 “synth on a chip” for each of it's six voices. The CEM3394

IC contains the VCO, VCF & VCA.

The Oscillator Tune and Range are combined and placed on the Oscillator 2 Tune (coarse) and Fine Tune

controls.

The Filter Keyboard Track has three possible levels, Off, 50% and 100% and the Filter Mode button will invert the

filter envelope. Green is a normal envelope and red is inverted.

The Sixtrak needs to be placed into Parameter Edit mode by pressing Control Record then pressing 4.

This patch can also be used on the Sequential Circuits MAX. The MAX needs to be put into parameter edit mode

by pressing 'Erase' and then keying in 34. The default midi channel on the MAX is 3. The MAX has no unison

function and the Filter LFO has no function.
