SYNTH TABLES
Korg DW-8000
Cable and MIDI requirements
The Korg DW8000 uses a standard MIDI cable, Parameter 84 needs to be set to the same
channel number that is programmed into the Patch Editor (or set to Omni using Parameter 86).
Parameter 85 needs to be set to 2 to enable SysEx control.
KORG
©
DW-8000 Controls Pg1
Osc 1 Range (1) 16', 8', 4' LFO1 Wave (26) Triangle, Sawtooth, Square, Random
Osc 1 Wave (2) 16 Preprogrammed Wave types LFO1 Delay (27) Active
Osc 1 PW (3) Not Used LFO1 Speed (28) Active
Osc 1 Tune (4) Not Used Chorus/FX Rate (29) FX Delay Rate
Osc 1 LFO Mod (5) Active - Effects both Osc 1 & 2 Chorus/FX Mode (30) Not Used
Osc 1 ENV Mod (6) Not Used HPF (31) Not Used
Osc 1 Mode (7) Key Assign Mode, Poly 1 & 2, Unison 1 & 2 LPF Cutoff (32) Active
Osc 1 PWM (8) Not Used LPF Resonance (33) Active
Osc 1 Level (9) DCO 1 Level Filter LFO Modulation (34) Active
Noise Level (10) Active Filter ENV Modulation (35) Active
Osc 2 Range (15) 16', 8', 4' Filter Key Follow (36) Active
Osc 2 Wave (16) 16 Preprogrammed Wave types Filter ADSR EG1 (37-40) Active
Osc 2 PW (17) Not Active Filter Mode (41) Filter Envelope Polarity
Osc 2 Tune (18) Osc 2 Interval (unison, minor 3rd, major 3rd, perfect 4th
and perfect 5th)
VCA ADSR EG2 (42-45) Active
Osc 2 Fine Tune (19) Osc 2 Detune VCA Mode (46) Not Used
Osc 2 LFO Mod (20) FX Delay Feedback VCA Level (47) FX Delay Level
Osc 2 ENV Mod (21) FX Delay Intensity
Osc 2 Mode (22) FX Delay time (Eight Settings)
Osc 2 PWM (23) FX Delay Factor - adjusts Delay time by a small amount
Osc 2 XMod (24) Not Used
Osc 2 Level (25) DCO 2 Level
KORG
©
DW-8000 Controls Pg2
Osc 1 Range (1) Auto Bend Select - Off, Osc 1, Osc 2, Both LFO1 Wave (26) Not Used
Osc 1 Wave (2) Auto Bend Mode - Up, Down LFO1 Delay (27) Not Used
Osc 1 PW (3) Auto Bend Time LFO1 Speed (28) Not Used
Osc 1 Tune (4) Not Used Chorus/FX Rate (29) Not Used
Osc 1 LFO Mod (5) Auto Bend Intensity Chorus/FX Mode (30) Not Used
Osc 1 ENV Mod (6) Not Used HPF (31) Not Used
Osc 1 Mode (7) Not Used LPF Cutoff (32) Active
Osc 1 PWM (8) Not Used LPF Resonance (33) Active
Osc 1 Level (9) Not Used Filter LFO Modulation (34) Filter Env Attack
Noise Level (10) Portamento Amount Filter ENV Modulation (35) Filter Env Decay
Osc 2 Range (15) Not Used Filter Key Follow (36) Filter Env Break Point
Osc 2 Wave (16) Not Used Filter Attack Filter Env Slope
Osc 2 PW (17) Not Used Filter Decay Filter Env Sustain
Osc 2 Tune (18) Osc Bend Amount Filter Sustain Filter Env Release
Osc 2 Fine Tune (19) Not Used VCF Mode VCF Bend Mode - Off, On
Osc 2 LFO Mod (20) Aftertouch Osc MG Filter Release VCA Env Attack
Osc 2 ENV Mod (21) Aftertouch VCF VCA Attack VCA Env Decay
Osc 2 Mode (22) Not Used VCA Decay VCA Env Break Point
Osc 2 PWM (23) Aftertouch VCA VCA Sustain VCA Env Slope
Osc 2 XMod (24) Not Used VCA Release VCA Env Sustain
Osc 2 Level (25) Not Used VCA Mode (46) Not Used
VCA Level (47) VCA Env Release
Korg DW-8000 Notes
The DW-8000 uses two separate voice generators which are not VCOs but rather are preprogrammed wave form
generators which change their frequency depending on the note played. The waveforms are generated from
ROM (Read Only Memory) look up tables and the frequencies are calculated in real time by very fast hardware
multipliers and a DAC (Digital to Analog Converter) to produce the final waveform. A more conventional filter and
VCA is used which uses the NJM2069 combo chip for each of the 8 voices.
The oscillators 1 and 2 Range buttons are used to step through all possible octaves. These are 16', 8' and 4'.
The oscillators 1 and 2 Wave buttons are used to step though all possible programmed wave types. These are
Brass & Strings, Clarinet, Acoustic Piano, Electric Piano, Electric Piano Hard, Clavicord ,Organ, Brass,
Saxophone, Violin, Acoustic Guitar, Guitar (distorted), Electric Bass, Digital Bass, Bell and Organ/Whistle.
The Oscillator 2 tune will change the oscillator 1 and 2 interval. Possible interval options are unison (same as
Oscillator 1) , minor 3rd, major 3rd, perfect 4th and perfect 5th. The Fine Tune control on the Patch Editor will
provide Oscillator 2 Detune.
The Oscillator 1 LFO modulation control will effect both oscillators 1 and 2.
The Envelopes in the DW-8000 use extra controls. In addition to Attack, Decay, Sustain and Release there are
break level and slope controls. On page 1 the Patch Editor sets the slope equal to the decay and the break level
to maximum and break time to minimum which has the effect of changing the envelope generators to the four
control system. On page two full control is provided.
The DW8000 has a comprehensive delay section. This has been placed in the unused Oscillator 2 modulation
area, the FX/Chorus rate control & the VCA Level control is used to set the Delay level.
www.kiwitechnics.com Patch Editor v6.0
