KiwiTechnics Kiwi-3P Upgrade
Cable requirements
The Roland 3P KiwiTechnics Upgrade uses a standard MIDI cable
The KiwiTechnics 3P upgrade is a complete rewrite of the operating system in the Roland JX-3P synthesizer. Many
enhancements have been made and to enable control of them all the KiwiTechnics 3P Upgrade has been split over two
control pages.
Roland© JX-3P KiwiTechnics Upgrade Controls Page 1
Osc 1 Range (1) 16', 8', 4' LFO1 Wave (26) Sine,Tri, Saw, Rev Saw, Sqr, Random
Osc 1 Wave (2) Sawtooth, Pulse, Square LFO1 Delay (27) Active
Osc 1 PW (3) Not Used LFO1 Speed (28) Active
Osc 1 Tune (4) DCO1 Tune +-12 Semitones Chorus/FX Rate (29) Chorus Auto Speed or Manual Position
Osc 1 LFO Mod (5) DCO 1 LFO Level - See page 2 for LFO Source Chorus/FX Mode (30) Chorus Auto, Chorus Manual, Chorus Off
Osc 1 ENV Mod (6) DCO 1 ENV Level - note split ± 63 control HPF (31) Off, 10% to 100% in 11 steps
Osc 1 Mode (7) Select DCO 1 EG Source - EG1 or EG2 LPF Cutoff (32) Active
Osc 1 PWM (8) Not Used LPF Resonance (33) Active
Osc 1 Level (9) Osc 1 & 2 Mix Filter LFO Mod (34) Filter LFO Level - See page 2 for LFO Source
Noise Level (10) Portamento Rate Filter ENV Mod (35) VCF ENV Level - note split ± 63 control
Osc 2 Range (15) 16', 8', 4' Filter Key Follow (36) Active
Osc 2 Wave (16) Sawtooth, Pulse, Square, Noise EG1 ADSR (37-40) Active
Osc 2 PW (17) Not Used Filter Mode (41) Select Filter EG - EG1 or EG2
Osc 2 Tune (18) DCO2 Tune ±12 Semitones EG2 ADSR (42-45) Active
Osc 2 Fine Tune (19) DCO2 Fine Tune ±50 Cents VCA Mode (46) Select VCA - Gate, EG1 or EG2
Osc 2 LFO Mod (20) DCO 2 LFO Level - See page 2 for LFO Source VCA Level (47) Active
Osc 2 ENV Mod (21) DCO 2 ENV Level - note split ± 63 control
Osc 2 Mode (22) Select DCO 2 EG Source - EG1 or EG2
Osc 2 PWM (23) Not Used
Osc 2 XMod Sync Off, Sync On, Metal
Osc 2 Level (25) Not Used
Roland© JX-3P KiwiTechnics Upgrade Controls Page 2
Osc 1 Range (1) Arpeggiator Mode - Up, Down, U&D, Random LFO 2 Wave (26) Sine,Tri, Saw, Rev Saw, Sqr, Random
Osc 1 Wave (2) Arpeggiator Range - 0, 1 or 2 Octaves LFO 2 Delay (27) Active
Osc 1 PW (3) Not Used LFO 2 Speed (28) Active
Osc 1 Tune (4) Not Used Chorus/FX Rate (29) Key Assign Detune
Osc 1 LFO Mod (5) Not Used Chorus/FX Mode (30) Key Mode - Poly 1,2 Mono 1,2 Unison 1,2
Osc 1 ENV Mod (6) Not Used HPF (31) Bend Level Dest - DCO, VCF, VCA
Osc 1 Mode (7) Select DCO 1 LFO Source - LFO1, LFO2 LPF Cutoff (32) Active
Osc 1 PWM (8) Not Used LPF Resonance (33) Active
Osc 1 Level (9) Not Used Filter LFO Modulation
(34)
Active
Noise Level (10) Portamento Rate Filter ENV Modulation
(35)
Active
Osc 2 Range (15) Seq Clock Source Filter Key Follow (36) Active
Osc 2 Wave (16) Arp Clock Source EG1 ADSR (37-40) Not Used
Osc 2 PW (17) Aftertouch Level - note split ± 63 control Filter Mode (41) Select Filter LFO Source - LFO1, LFO2
Osc 2 Tune (18) Modulation Level - note split ± 63 control EG2 ADSR (42-45) VCA LFO Mod Level on Release
Osc 2 Fine Tune (19) Not Used VCA Mode (46) Select VCA LFO Source - LFO1, LFO2
Osc 2 LFO Mod (20) Not Used VCA Level (47) Active
Osc 2 ENV Mod (21) Not Used
Osc 2 Mode (22) Select DCO 2 LFO Source - LFO1, LFO2
Osc 2 PWM (23) Not Used
Osc 2 XMod Pattern Clock Source
Osc 2 Level (25) Pattern Level
Roland© KiwiTechnics JX-3P Upgrade Notes
The oscillator design in the JX-3P is a digital system and the filter uses the custom Roland chip the IR3109 for each of the six
voices. The KiwiTechnics Upgrade has realized the full potential of the 3P and provides full midi control for all parameters.
More details can be found in the KiwiTechnics 3P Upgrade manual.
