SYNTH TABLES
Korg DSM-1
Cable and MIDI requirements
The Korg DSM-1 uses a standard MIDI cable.
Korg DSM-1 Page 1 Controls
Osc 1 Range (1) Not Used LFO Wave (26) OSC MG Wave (Sine, Tri, Square)
Osc 1 Wave (2) Not Used LFO Delay (27) OSC MG Delay
Osc 1 PW (3) Multi Sound Number LFO Speed (28) OSC MG Rate
Osc 1 Tune (4) Tune (+-) Chorus/FX Rate (29) Not Used
Osc 1 LFO Mod (5) OSC MG Intensity Chorus/FX Mode (30) Not Used
Osc 1 ENV Mod (6) Pitch Bend Range HPF (31) Not Used
Osc 1 Mode (7) Not Used LPF Cutoff (32) Active
Osc 1 PWM (8) Not Used LPF Resonance (33) Not Used
Osc 1 Level (9) Not Used Filter LFO Modulation (34) VCF MG Intensity
Noise Level (10) Not Used Filter ENV Modulation (35) VCF EG Intensity
Osc 2 Range (15) Not Used Filter Key Follow (36) Active
Osc 2 Wave (16) Not Used Filter ADSR EG1 (37-40) Active (ADSR only)
Osc 2 PW (17) Auto Bend Direction (Up/Down) Filter Mode (41) VCF EG Polarity
Osc 2 Tune (18) Auto Bend Time VCA ADSR EG2 (42-45) Active (ADSR only)
Osc 2 Fine Tune (19) Auto Bend Intensity VCA Mode (46) Not Used
Osc 2 LFO Mod (20) Not Used VCA Level (47) Active
Osc 2 ENV Mod (21) Not Used
Osc 2 Mode (22) OSC Auto Bend Polarity
Osc 2 PWM (23) Not Used
Osc 2 XMod (24) Not Used
Osc 2 Level (25) Not Used
Korg DSM-1 Page 2 Controls
Osc 1 Range (1) Not Used LFO Wave (26) VCF MG Wave (Sine, Tri, Square)
Osc 1 Wave (2) Not Used LFO Delay (27) VCF MG Delay
Osc 1 PW (3) Not Used LFO Speed (28) VCF MG Rate
Osc 1 Tune (4) Not Used Chorus/FX Rate (29) Not Used
Osc 1 LFO Mod (5) Not Used Chorus/FX Mode (30) Not Used
Osc 1 ENV Mod (6) Not Used HPF (31) Not Used
Osc 1 Mode (7) Not Used LPF Cutoff (32) VCF Cutoff Aftertouch
Osc 1 PWM (8) Not Used LPF Resonance (33) Bender VCF Sweep Intensity
Osc 1 Level (9) Not Used Filter LFO Modulation (34) VCF MG Init After Touch
Noise Level (10) Not Used Filter ENV Modulation (35) Not Used
Osc 2 Range (15) Not Used Filter Key Follow (36) Not Used
Osc 2 Wave (16) Not Used Filter ADSR EG (37-40) VCF Attack, Decay, Slope Aftertouch Sense
Osc 2 PW (17) Not Used Filter Mode (41) Not Used
Osc 2 Tune (18) Not Used VCA ADSR EG2 (42-45) VCA Attack, Decay, Slope Aftertouch Sense
EG Release Keytrack
Osc 2 Fine Tune (19) Not Used VCA Mode (46) Not Used
Osc 2 LFO Mod (20) Auto Bend Touch Sens Intensity VCA Level (47) Total Level Aftertouch Sense
Osc 2 ENV Mod (21) Not Used
Osc 2 Mode (22) Not Used
Osc 2 PWM (23) Not Used
Osc 2 XMod (24) Not Used
Osc 2 Level (25) Not Used
Note: The DSM-1 that we used for testing had a bad audio glitch everytime parameter change midi was sent to it.
www.kiwitechnics.com Patch Editor v6.0
