Waldorf MicroWave 1
Cable and MIDI requirements
The Waldorf Patch uses a standard MIDI cable.
This Waldorf patch uses more controls than are available on the Patch Editor so this patch has been spread over two
pages. Menu button 3 will select the active page.
Waldorf MicroWave 1 Controls Page 1
Osc 1 Range (1) DCO1 Oct Shift (-2 > +2) LFO1 Wave (26) LFO 1 Sine, Saw, Pulse, Random
Osc 1 Wave (2) Not Used LFO1 Delay (27) LFO 1 Delay
Osc 1 PW (3) Not Used LFO1 Speed (28) LFO 1 Rate
Osc 1 Tune (4) DCO 1 Semitone Adjust Chorus/FX Rate (29) LFO 1 Modifier 1 Level
Osc 1 LFO Mod (5) DCO 1 Modifier 1 Level Chorus/FX Mode (30) LFO 1 Modifier 1 Source Select (17 types)
Osc 1 ENV Mod (6) DCO 1 Modifier 2 Level HPF (31) VCF Res Modifier 1 Source Select (17 types)
Osc 1 Mode (7) DCO 1 Modifier 1 Source Select (17 types) LPF 1 Cutoff (32) VCF 1 Cutoff
Osc 1 PWM (8) DCO 1 Modifier 2 Source Select (17 types) LPF 1 Resonance (33) VCF 1 Resonance
Osc 1 Level (9) Wave 1 Level Filter 1 LFO Mod (34) VCF 1 Modifier 1 Level
Noise Level (10) Noise Level Filter 1 ENV Mod (35) VCF 1 Envelope Level
Osc 2 Range (15) DCO2 Oct Shift (-2 > +2) Filter Key Follow (36) VCF 1 Keytrack
Osc 2 Wave (16) Not Used Filter ADSR EG1 (37-40) VCF Env A/D/S/R
Osc 2 PW (17) DCO 2 Pulse Width Filter Mode (41) VCF Modifier 1 Source Select (17 types)
Osc 2 Tune (18) DCO 2 Semitone Adjust VCA ADSR EG2 (42-45) VCA Env A/D/S/R
Osc 2 Fine Tune (19) DCO 2 Detune VCA Mode (46) Not Used
Osc 2 LFO Mod (20) DCO 2 Modifier 1 Level VCA Level (47) Total volume
Osc 2 ENV Mod (21) DCO 2 Modifier 2 Level
Osc 2 Mode (22) DCO 2 Modifier 1 Source Select (17 types)
Osc 2 PWM (23) DCO 2 Modifier 2 Source Select (17 types)
Osc 2 XMod (24) Not Used
Osc 2 Level (25) Wave 2 Level
Waldorf MicroWave 1 Controls Page 2
Osc 1 Range (1) Not Used LFO Wave (26) LFO 2 Sine, Saw, Pulse, Random
Osc 1 Wave (2) Not Used LFO Delay (27) LFO 2 Delay
Osc 1 PW (3) Wave 1 Start Position LFO Speed (28) LFO 2 Rate
Osc 1 Tune (4) Wave 1 Start Sample Chorus/FX Rate (29) LFO 2 Symmetry
Osc 1 LFO Mod (5) Wave 1 Modifier 1 Amount Chorus/FX Mode (30) LFO 2 Humanize Type
Osc 1 ENV Mod (6) Wave 1 Envelope Amount HPF (31) Not Used
Osc 1 Mode (7) Wave 1 Modifier 1 Source Select (17 types) LPF Cutoff (32) VCF Cutoff
Osc 1 PWM (8) Wave 1 Modifier 2 Amount LPF Resonance (33) VCF Resonance Mod 1 Amount
Osc 1 Level (9) Wave 1 Keytrack Amount Filter LFO Mod (34) VCF Modifier 1 Level
Noise Level (10) Not Used Filter ENV Mod (35) VCF Envelope Level
Osc 2 Range (15) Not Used Filter Key Follow (36) VCF Keytrack
Osc 2 Wave (16) Not Used Filter ADSR EG1 (37-40) Not Used
Osc 2 PW (17) Wave 2 Start Position Filter Mode (41) Not Used
Osc 2 Tune (18) Wave 2 Start Sample VCA ADSR EG2 (42-45) Not Used
Osc 2 Fine Tune (19) Wave 1 & 2 Wave Table VCA Mode (46) Not Used
Osc 2 LFO Mod (20) Wave 2 Modifier 1 Amount VCA Level (47) VCA Volume Envelope Amount
Osc 2 ENV Mod (21) Wave 2 Envelope Amount
Osc 2 Mode (22) Wave 2 Modifier 1 Source Select (17 types)
Osc 2 PWM (23) Wave 2 Modifier 2 Amount
Osc 2 XMod (24) Not Used
Osc 2 Level (25) Wave 2 Keytrack Amount
