Oberheim Matrix 6
Cable and MIDI requirements
The Oberheim Matrix 6 uses a standard MIDI cable.
Oberheim Matrix 6 Page 1 Controls
Osc 1 Range (1) Not Used LFO1 Wave (26) Tri, Up Saw, Down Saw, Sqr, Random, Noise,
Sample Mod
Osc 1 Wave (2) Osc 1 Wave (Off Pulse, Wave, Both) LFO1 Delay (27) LFO 1 Initial Amplitude
Osc 1 PW (3) DCO 1 Initial Pulse Width Amount LFO1 Speed (28) LFO 1 Rate
Osc 1 Tune (4) DCO 1 Initial Frequency Semitones Chorus/FX Rate (29) Portamento Initial Rate
Osc 1 LFO Mod (5) DCO 1 Freq by LFO 1 Modulation Amount Chorus/FX Mode (30) Legato Portamento Enable
Osc 1 ENV Mod (6) OSC 1 Initial Wave Shape HPF (31) VCF Fixed Mods (Off, Level 1, Vibrato, Both)
Osc 1 Mode (7) OSC 1 Fixed Mods (Off, Level 1, Vibrato, Both) LPF Cutoff (32) Active
Osc 1 PWM (8) DCO 1 PW by LFO2 Modulation Amount LPF Resonance (33) Active
Osc 1 Level (9) Oscillator 1 <> 2 Mix Filter LFO Modulation (34) VCF FM Amount
Noise Level (10) Not Used Filter ENV Modulation (35) VCF Env 1 Amount
Osc 2 Range (15) Not Used Filter Key Follow (36) VCF Pressure Mod Amount
Osc 2 Wave (16) Osc 2 Wave (Off Pulse, Wave, Both) Filter ADSR EG1 (37-40) Env 1
Osc 2 PW (17) DCO 2 Initial Pulse Width Amount Filter Mode (41) Env 1 Trigger Mode
Osc 2 Tune (18) DCO 2 Tune Semitones VCA ADSR EG2 (42-45) Env 2
Osc 2 Fine Tune (19) DCO 2 Detune Cents VCA Mode (46) Env 2 Trigger Mode
Osc 2 LFO Mod (20) DCO 2 Freq by LFO 2 Modulation Amount VCA Level (47) VCA Initial Level
Osc 2 ENV Mod (21) OSC 2 Initial Wave Shape
Osc 2 Mode (22) OSC 1 Fixed Mods (Off, Level 1, Vibrato, Both)
Osc 2 PWM (23) DCO 2 PW by LFO2 Modulation Amount
Osc 2 XMod (24) Sync On/Off
Osc 2 Level (25) Not Used
Oberheim Matrix 6 Page 2 Controls
Osc 1 Range (1) OSC 1 Click (On/Off) LFO Wave (26) LFO 2 Tri, Up Saw, Down Saw, Sqr, Random,
Noise, Sample Mod
Osc 1 Wave (2) Tracking Input Select (20 types) LFO Delay (27) LFO 2 Initial Amplitude
Osc 1 PW (3) Tracking Point 1 LFO Speed (28) LFO 2 Rate
Osc 1 Tune (4) Tracking Point 2 Chorus/FX Rate (29) Not Used
Osc 1 LFO Mod (5) Tracking Point 3 Chorus/FX Mode (30) Key Assign Mode (4 types)
Osc 1 ENV Mod (6) Tracking Point 4 HPF (31) VCF Keyboard Mod (Key, Portamento)
Osc 1 Mode (7) Not Used LPF Cutoff (32) Active
Osc 1 PWM (8) Tracking Point 5 LPF Resonance (33) Active
Osc 1 Level (9) Not Used Filter LFO Modulation (34) Not Used
Noise Level (10) Not Used Filter ENV Modulation (35) Env 1 Initial Delay
Osc 2 Range (15) OSC 2 Click (On/Off) Filter Key Follow (36) Env 2 Initial Delay
Osc 2 Wave (16) Not Used Filter ADSR EG1 (37-40) Env 3 Initial Delay (on VCF Release Slider)
Osc 2 PW (17) Not Used Filter Mode (41) Env 1 Mode (DADR/Free run)
Osc 2 Tune (18) Not Used VCA ADSR EG2 (42-45) Env 3 ADSR
Osc 2 Fine Tune (19) Not Used VCA Mode (46) Env 2 Mode (DADR/Free run)
Osc 2 LFO Mod (20) Not Used VCA Level (47) Active
Osc 2 ENV Mod (21) Not Used
Osc 2 Mode (22) Not Used
Osc 2 PWM (23) Not Used
Osc 2 XMod (24) Not Used
Osc 2 Level (25) Not Used
Oberheim Matrix 6 Notes
Some Sysex commands on the Oberheim Matrix 6 are very slow responding to sysex and it does not respond
well to large numbers of commands in rapid succession. With some commands to the Matrix 6 the synth will
stop responding for 1-2 seconds and hang notes or have other random problems until it catches up. This makes
it unsuitable to control parameters in a live situation but a patch has been provided to help set up the Matrix 6.
