SYNTH TABLES
Studio Electronics ATC
Cable and MIDI requirements
The Studio Electonics ATC uses a standard MIDI cable.
Studio Electronics ATC Controls
Osc 1 Range (1) Not Used LFO1 Wave (26) LFO 1 Wave (6 types)
Osc 1 Wave (2) Wave type (3 types & 4 mixes) LFO1 Delay (27) Not Used
Osc 1 PW (3) Osc 1 Pulse Width LFO1 Speed (28) LFO Osc 1 Rate
Osc 1 Tune (4) Osc 1 Frequency Chorus/FX Rate (29) Not Used
Osc 1 LFO Mod (5) Osc 1 LFO Depth Chorus/FX Mode (30) Not Used
Osc 1 ENV Mod (6) Not Used HPF (31) Filter Cartridge Type (4 types)
Osc 1 Mode (7) Not Used LPF Cutoff (32) Active
Osc 1 PWM (8) Not Used LPF Resonance (33) Active
Osc 1 Level (9) Oscillator 1 Level Filter LFO Modulation (34) Not Used
Noise Level (10) Noise Level Filter ENV Modulation (35) VCF Env 1 Depth
Osc 2 Range (15) Not Used Filter Key Follow (36) Active
Osc 2 Wave (16) Wave type (3 types & 4 mixes) Filter ADSR EG1 (37-40) Active
Osc 2 PW (17) Osc 2 Pulse Width Filter Mode (41) Envelope Mode
Osc 2 Tune (18) Osc 2 Frequency VCA ADSR EG2 (42-45) Active
Osc 2 Fine Tune (19) Osc 2 Fine Tune VCA Mode (46) Not Used
Osc 2 LFO Mod (20) Osc 2 LFO Depth VCA Level (47) Active
Osc 2 ENV Mod (21) Not Used
Osc 2 Mode (22) Not Used
Osc 2 PWM (23) Cross Mod Amount
Osc 2 XMod (24) Osc 2 Sync Control (Normal & 3 types)
Osc 2 Level (25) Oscillator 2 Level
Osc 1 Range (1) Not Used LFO1 Wave (26) LFO 2 Wave (6 types)
Osc 1 Wave (2) Not Used LFO1 Delay (27) Not Used
Osc 1 PW (3) Not Used LFO1 Speed (28) LFO Osc 2 Rate
Osc 1 Tune (4) Not Used Chorus/FX Rate (29) Not Used
Osc 1 LFO Mod (5) Not Used Chorus/FX Mode (30) Not Used
Osc 1 ENV Mod (6) Not Used HPF (31) Not Used
Osc 1 Mode (7) Not Used LPF Cutoff (32) Active
Osc 1 PWM (8) Not Used LPF Resonance (33) Active
Osc 1 Level (9) Not Used Filter LFO Modulation (34) Not Used
Noise Level (10) Not Used Filter ENV Modulation (35) Not Used
Osc 2 Range (15) Not Used Filter Key Follow (36) Not Used
Osc 2 Wave (16) Not Used Filter ADSR EG1 (37-40) Envelope 3
Osc 2 PW (17) Not Used Filter Mode (41) Not Used
Osc 2 Tune (18) Not Used VCA ADSR EG2 (42-45) Not Used
Osc 2 Fine Tune (19) Not Used VCA Mode (46) Not Used
Osc 2 LFO Mod (20) Not Used VCA Level (47) Active
Osc 2 ENV Mod (21) Not Used
Osc 2 Mode (22) Not Used
Osc 2 PWM (23) Not Used
Osc 2 XMod (24) Not Used
Osc 2 Level (25) Not Used
Studio Electronics ATC Notes
Some commands that are available on the ATC have no midi equivalent and cannot be edited using midi
parameter edits. Every available command has been included in this patch.
www.kiwitechnics.com Patch Editor v6.0
