SECTION 12
PARTS LISTS
Jan 2003
page 12-4
80073505
Figure 12-1. WATERJET PUMP 80072648
ITEM No. QTY. PART No. DESCRIPTION
1 1 80072804 Frame Assembly
2 1 80072978 Hydraulic Power Package
3 1 80073083 Electrical Assembly
4 1 80073703 Decal Package
21 4 05059605 Spring
24 -- 05022702 Hydraulic Fluid
25 1 05128087 Start-Up Tag
26 1 05135702 Test Report
27 1 80073000 Hydraulic Hose Connections
28 1 80074073 Reservoir Assembly
29 1 80073661 Bulkhead Pipe Assembly
31 1 80072655 HP Water Assembly
