SECTION 12
PARTS LISTS
Jan 2003
page 12-6
80073505
Figure 12-2. INTENSIFIER ASSEMBLY 05144217
ITEM No. QTY. PART No. DESCRIPTION
1 2 05144647 Body, Cylinder, HP, 1.13-in. ID
2 2 05119151 Plunger, Ceramic
3 2 05144688 Head Assembly, Sealing
4 2 05147913 Head, Cylinder
5 2 05149703 HP Seal Assembly
6 2 05144696 Sealing Head Spacer
7 2 05144225 Flange Ring
8 2 05130091 Low Pressure Hydraulic Cartridge Seal Assembly
9 2 05007786 Bushing Retaining Flange
10 12 05144753 Stud, 7/8-9 x 6.00
11 2 05144712 Liner, HP Cylinder
12 4 10074904 O-ring
13 2 05144209 End Flange
14 2 05034798 Ring, Retaining
15 1 05034764 Cylinder, Hydraulic
16 2 10075000 O-ring
17 2 05034855 Ring, Backup
18 16 05141106 Cap Screw, Socket Head, M14x60
19 2 05127584 Switch, Proximity, 20-250 VAC/VDC
20 4 10183572 Cap Screw, Socket Head, M6x1x22mm, 316/304 Stainless
21 1 05132253 Piston Assembly, Hydraulic
22 12 10069904 Heavy Hex Nut, 7/8-9
23 2 05049812 Mounting Stem
25 8 05079652 Cap Screw, Socket head, M10 x 1.5 x 85mm, Grade 12.6
26 8 05061486 Washer, Lock, High Collar, M10, Stainless
27 2 10074409 O-ring
28 2 05144183 Spacer, Proximity Switch
29 2 05081872 Gasket, Drip Pan, Upper
30 * 10148674 Special Tool, HP Seal Removal (Not Shown)
31 * 05066139 Special Tool, Wrench, HP Cylinder (Not Shown)
32 * 05004924 Special Tool, Plunger Removal
