Desk with Extension Top or Cabinet (With Legs Under Worksurface)
Exploded Desk with Extended Rails Detail
Exploded Desk Assembly with
(3) Extension Options
End Cap With Tab (M)
Rail
W-Bracket (D)
Cradle Clamp Bracket (B)
Horizontal Rail Cradle (A)
Desk End Leg
Step 8
Steps 1 and 2
Step 3
Step 7
Step 7b
(above desk
extension
cabinet)
Step 7a
(extension top)
Step 7c
(below desk
extension
cabinet)
Step 9 (optional)
12"
¼-20 x
5
/
8
" Machine Screw (F)
¼-20 x 1" Machine
Screw (E)
#14 x 1" FH Wood Screw (G)
#14 x 1" FH Wood Screw (G)
#14 x 1" FH Wood Screw (G)
Spacer (C) with #12 X ¾"
Black Wood Screw (H)
Fabric Inserts are Installed in the Back
of Above Desk Extension Cabinets
To Next Page
