Knoll Antenna Workspaces - Page 53

Sapper Monitor Arm and Cantilever Shelf:
Center Beam Attachment
Step 6
Cantilever Shelf (D)
Step 5
½-12 x 1 ¼" Machine Screw (E)
Cantilever Shelf Support (C)
Post Extrusion (8)
Post Mounting Bracket (A)
M6-1 x 14mm
Machine Screw (G)
½-13 x 1 ¼"
Machine Screw (E)
Spring Nut (F) Center Beam
Exploded Beam-Mounted
Cantilever Shelf
Cantilever Shelf Beam
Mount Assembly
