Electrical Components: Surface Mounted Plugmold Raceway
Exploded Plugmold Raceway
Mounting Detail
(Installation with a Power Harness
Mounting Bracket for Desks or
a Center Beam for Big Tables)
Big Table with Surface Mounted Plugmold Raceway
Mounting Kit for Plugmold
Power Harness
Mounting Bracket
for Desks
Plugmold Mounting Rail (A)
Plugmold Assembly (D)
M6 x 10mm Machine Screw (C)
Step 1
Step 2
Center Beam
Spring Nut (B)
Center Beam Plugmold Raceway
(or)
To Next Page
