NOTE: The chart below references a compound cut for crown moulding ONLY WHEN
THE ANGLE BETWEEN THE WALLS EQUALS 90°.
Bevel/Miter Settings
KEY
BEVEL
SETTING
MITER
SETTING
TYPE OF CUT
Inside corner - Left side
IL 33.9° 31
.6° Right
1. Position top of moulding against fence.
2. Miter table set at RIGHT 31.6°.
3. LEFT side is finished piece.
Inside corner - Right side
IR 33.9° 31
.6° Left
1. Position bottom of moulding against fence.
2. Miter table set at LEFT 31.6°.
3. LEFT side is finished piece.
Outside corner - Left side
OL 33.9° 31
.6° Left
1. Position bottom of moulding against fence.
2. Miter table set at LEFT 31.6°.
3. RIGHT side is finished piece.
Outside corner - Right side
OR 33.9° 31
.6° Right
1. Position top of moulding against fence.
2. Miter table set at RIGHT 31.6°.
3. RIGHT side is finished piece.
