Product Specifications .......................................................................................... 2
Package Contents ............................................................................................... 3
Safety Information ................................................................................................ 4
Preparation ........................................................................................................... 1
0
Assembly Instructions .......................................................................................... 12
Adjustment Instructions ....................................................................................... 14
Operating Instructions .........................................................................................
25
Crown Moulding Chart .......................................................................................... 37
Care and Maintenance ......................................................................................... 38
Troubleshooting .................................................................................................... 40
Replacement Parts List and Exploded Views ....................................................... 4
1
W
arranty ............................................................................................................... 50
MOTOR CUTTING CAPACITY
Power Source
15A, 120V A/C,
60 Hz
Crosscut 3-1/2 in. x 12 in.
Arbor Shaft Size 5/8 in. Miter 45° Right & Left 3-1/2 in. x 8 in.
Speed (No load) 4800 RPM Bevel 45° Left 1-5/8 in. x 12 in.
Electric Brake Yes 45° Miter & 45° Bevel 1-5/8 in. x 8 in.
Double Insulated Yes Crown Moulding Nested 5-3/4 in.
BLADE Base Moulding Against Fence 3-1
/2 in.
Diameter 10 in. MITER/BEVEL
POSITIVE STOP ANGLES
Arbor 5/8 in. Miter Detent Stops
0°, 15°, 22.5°, 31.6°, 45°
R&L
Bevel Positive Stops 0°, 33.9°, 45° L
TABLE OF CONTENTS
PRODUCT SPECIFICATIONS
To Next Page
