I.D. Description Size Q’ty
3492 MOTOR REAR COVER 1
0HX9 NEEDLE BEARING 1
0JBA WAVE WASHER 1
0JCD SPRING PIN 1
0JE0 C-RING 1
0JEB C-RING 1
0JEE C-RING 1
0JG7 PARALLEL KEY 1
0JX2 HEX. SOC SET SCREW M5*0.8-6 2
0K43 CR.RE. PAN HD. SCREW & WASHER M5*0.8-16 2
0K44 CR.RE. PAN HD. SCREW & WASHER M5*0.8-12 1
0KAA CR.RE. PAN HD. TAPPING SCREW M5*12-16 2
0QGR COMPRESSION SPRING 1
0QMY PROTECTOR WIRE 1
0QQS BRUSH HOLDER ASS’Y 2
0QQT BRUSH ASS’Y 2
0QR0 BRUSH COVER 2
0QR2 BEARING BUSHING 1
110A CR.RE. PAN HD.TAPPING SCREW & WASHER M5*12-55 2
21AJ BEARING SEAT 1
2JEG CR.RE. PAN HD. SCREW & WASHER M5*0.8-30 4
2MGY FLOW GUIDE 1
2MHR GEAR BOX 1
2WR5 MOTOR COVER 1
31QW CUTTER SHAFT ASS’Y 1
31QV CUTTER SHAFT 1
32C5 BRACKET STOP ASS’Y 1
32GT HELIX GEAR 1
32U5 BALL BEARING 1
34G1 FIELD ASS’Y 1
34G2 ARMATURE ASS’Y 1
34G3 ARMATURE ASS’Y 1
35HQ LEAD WIRE ASS’Y 1
Y3Z9 BALL BEARING 1
Y3ZY BALL BEARING 1
PARTS LIST - MOTOR
