5)Entire the insulation or
front and rear end, or
core diameter gets
scratched.
6)The core diameter is
cut.
The core diameter is
is scratched
The blade is worn away or
chipped off？
The position of the blade is out
of alignment？（when replacing
the blade）
Isn’t the roller gap narrow？
Isn’t both left and right side or
one side of the pressure
strong？
The roller fits the wire?
Isn’t the 《Core Diameter》 or
《Blade Move Back》 small？
The size of the guide pipe fits
the wire？
Slugs of the insulation stick to
the cutting blade and they are
cut with processed wire all
together？
The blade is worn away or
chipped off？
Replacement of the blade.（See
P, 23）
Attach the blade again.
Widen it. （ See P,9 「 Roller Gap
Adjustment」）
Turn down the pressure.
Change the roller which fits the
wire, which is optional.
Make the 《 Core Diameter 》 or
《Blade Move Back》 larger to the
point where it becomes proper.
Change the wire guide and the
guide pipe which fit the wire,
which are optional.
Set half-strip. (Air doesn’t blow
out.) Or input “0” at half-strip and
use the solenoid valve.
Replacement of the blade.（See
P, 23）
7 ） “Total length of the
wire which is set” and
“Actually processed
total length” are
different.
It may happen depending on
the wire because the wire is
processed by being held.
Straightening part is too strong.
Set the 《Total Length Correction》.
（See P.6）
Adjust the strength of the
straightening part.（See P.5）
8 ） On the touch panel,
touched “function” and
the function which
actually reacts are
different.
Reactions of the touch panel are
not lined up.
Pressing [STOP] key and at the
power ON, perform the calibration.
※ When the causes are not clear, make each speed slow on the ［Machine Adj］ screen and try to
process.
By making the speed slower, you may check it visually.
