Kohler G220 User Manual

TP-6322 9/0444 Section 7 Service Parts
7.6 Enclosure, NEMA Type 3R
DP-295000
2
5
4
3
9
8
7
1
6
SECTION A--A
Item Part Number Description
1 362441 Enclosure (includes 353613, 353614, and 353708)
2 353613 Box
3 # Nut, hex, 10-32 (4)
4 X-67-52 Screw, hex washer, thread-forming, 10-32 x 0.500 (2)
5 353614 Cover
6 353708 Hasp
7 362126 Lug, terminal, copper
8 X-81-8 Nut, hex, 1/4-20
9 X-22-11 Washer, lock, .262 ID x .469 in. OD
# Common hardware. Procure locally.
