TP-6322 9/04 45Section 7 Service Parts
7.7 Neutral Lug, 100 Amp
DP-295000
1
2
3
4
5
7
8
6
Item Part Number Description
1 233269 Insulator, panel (2)
2 295304 Bracket, mounting
3 X-25-40 Washer, plain, .281 ID x .625 in. OD (2)
4 X-22-11 Washer, lock, .262 ID x .469 in. OD (2)
5 X-465-6 Bolt, 1/4-20 x .50 (2)
6 295303 Lug, terminal, aluminum (3)
7 X-22-9 Washer, lock, .20 ID x .373 in. OD (3)
8 X-97-11 Screw, slotted hex head machine, 10-32 x 0.500 (3)
