TP-6835 9/1710 Section 1 Product Description
1.3 Model Designation
Model Controls Voltage Poles Enclosure Current Rating ConnectionsMechanism Transition
Record the transfer switch model designation in the boxes. The transfer switch model designation defin es
characteristics and ratings as explained below.
Sample Model Designation: KBS-DMVA-1200S
Model
K: Kohler
Mechanism
B: Bypass/Isolation
Transition
S: Standard
P: Programmed
C: Closed
Controller
D:
Decision-Makerr MPAC 1500, Automatic
Voltage/Frequency
C: 208 Volts /60 Hz K: 440 Volts /60 Hz
D: 220 Volts / 50 Hz M: 480 Volts /60 Hz
F: 240 Volts /60 Hz N: 600 Volts /60 Hz
G: 380 Volts/ 50 Hz P: 380 Volts /60 Hz
H: 400 Volts / 50 Hz R: 220 Volts/ 60 Hz
J: 416 Volts /50 Hz
Number of Poles/Wires
N: 2 Poles/ 3 Wires, Solid Neutral
T: 3 Poles/ 4 Wires, Solid Neutral
V: 4 Poles/ 4 Wires, Switched Neutral
W: 4 Poles/ 4 Wires, Overlapping Neutral
Enclosure
A: NEMA 1
Current, Amps *
0150 0800 2600
0225 1000 3000
0260 1200 4000
0400 1600
0600 2000
* Some selections are not available on all models.
Connections
S: Standard
F: Front (800 amp only)
Note: Some selections are not available on all models.
Contact your Kohler distributor for availability.
