TP-6835 9/17 41Section 4 Communication and Accessory Connections
GM23469
Figure 4-22 Load Shed Accessory (for
identification)
GM89713
1. Input/output terminal strip TB1
1
TB1
12
6
1
7
MLB Input 2
(alternate
connection)
#12--24 AWG wire
0.5 Nm (4.4 in. lb.)
MLB
Input 1
MPAC Controller Circuit Board
Figure 4-23 Forced Transfer to Off Input Connection (for factory-installed load shed kits)
