Kohler KDI 2504 M-MP User Manual

5
23
_00
Fig. 5.1
Fig. 5.2
A
C
MIN
MAX
B
B
ED0053031100
INFORMATION ABOUT MAINTENANCE
EN
5.3 Oil level check
Important
• Place engine on horizontal surface to ensure accurate
measurement of checking.
1 - Loosen the oil filler cap A.
Remove the oil dipstick B and check that the level is up to
MAX.
2 - Pour in recommended oil until reaching the MAX level
mark.
3 - Reinstall the oil dipstick B completely.
4 - Re-tighten the cap A and/or C.
Important
• Do not exceed the MAX level on the dipstick.
• Do not use the engine with the oil level below the MIN.
