2
9
_00
620
687
992
ED0053031100
INFORMAZIONI TECNICHE
IT
CARATTERISTICHE TECNICHE
UNITÀ DI
MISURA
MODELLO MOTORE KDI 1903 M-MP KDI 2504 M-MP
CILINDRI n. 3 4
ALESAGGIO mm 88 88
CORSA mm 102 102
CILINDRATA cm
3
1861 2482
INCLINAZIONE MASSIMA DURANTE IL
FUNZIONAMENTO (anche in combinato)
trasversale
a
35° MAX 35° MAX
longitudinale
a
15° MAX 15° MAX
CAPACITÀ OLIO
(livello MAX.)
con ltro olio montato
versione standard lt. 8.9 11.5
PESO A SECCO kg 277 300
2.1 Descrizione generale motore
- Diesel 4 tempi con cilindri in linea;
- Raffreddamento a liquido;
- 4 valvole per cilindro con punterie idrauliche;
- Iniezione diretta.
2.2 Dati tecnici motore
2.3 Ingombro motore (mm) - con invertitore di marcia TMC 260
Tab. 2.1
