SIDE VIEW A
SIDE VIEW B
1.5 Engine component identication
GENERAL INFORMATION
Oil pressure
switch and
sensor
Thermostat
Oil filler cap
Coolant pump
Water pump
Starter motor
Oil filler cap
Coolant rell cap
Raiser
Cooled exhaust manifold
Coolant tempera-
ture sensor
Nameplate
Alternator
Coolant filler cap
Cooled exhaust manifold
Fuel injection pump
Oil lter
Nameplate
Raiser
Fuel lter
Air lter
Engine oil
extraction pump
Reversing
gear
