K20s
ChapterⅢ Web UI Configuration
§3.1 Overview
With the help of smart embedded Linux operating system and KOLIDA intelligent cloud
technology, we can configure and monitor the status of K20s on WEB UI. There are two ways to
access K20s' WEB UI, by WIFI hotspot and by USB Ethernet mode.
WIFI mode
First of all, get into WIFI Config option to open the WIFI hotspot by choosing AP option in
WIFI Option.
Then use smartphone, tablet or laptop to connect the WIFI hotspot (KOLIDA_xxxx) and input
the default IP (10.1.1.1) into explorer, input the default username and password for login.
USB mode
First of all, choose the Ethernet option in “System Option—Other option—USB Mode” to make
the 7-pin port be an ethernet port, then connect K20s with computer via USB cable. Run the IE
explorer and type IP 192.168.155.155 into IP address bar, then input the default username
(admin) and password (admin) for login.
NOTE: install the corresponding driver to activate this function, the driver can be downloaded
from official website.
Remote Login
If users would like to remote login the web UI of K20s, then K20s has to connect to the internet
and forward its 80 port to the public network. For example, if the IP address 222.196.35.76 is the
public network IP which K20s has connected, and the 80 port of K20s has been bounded with
8000 in public network, then users can input the public network IP address into IE explorer
along with the forwarding port for login. (http:// 222.196.35.76:8000)
NOTE: please use the IE explorer for the Web UI login.
In this chapter, we will take “using the WIFI hotsopt to login the Web UI” for example.
Turn on the WIFI hotspot of K20S then search for the SSID by computer. Then connect the
WIFI hotspot from K20S.
