K20s
- 65 -
Chapter
Ⅴ
Accessories
§
5.1 Instrument Ca
se and
Accesso
ries
Rover Receiver and Accessories
①
---
Carbon Fiber Pole
②
---
7-Pins
cable
for
connect
in
the
receiver
with
computer
for
static
data
transmission, Web UI accessing and firmware update.
③
---
K20s Receiver
④
---
Charg
er for K20s Receiver
⑤
---
Instrument Case
⑥
---
Height measurement piece
⑦
---
UHF
Antenna
①
③
②
④
⑤
⑥
⑧
⑦
64
66
