K20s
§6.2.2 By using radio (external radio)
§6.2.2.1 Base station setup
1) Set a tripod to the location with known coordinates (or unknown), attach base receiver to
the tribrach adapter set (the measuring plate is recommended to install under base receiver).
2) Mount the UHF antenna set onto a tripod, and connect it to the external radio which is
linked with the external power supply via the multi-function cable.
3) Power on the base receiver and set the receiver as base with external radio mode. (set on the
control panel, or on internal Web UI or on the software installed on data collector).
