UAB AMALVA we reserve the right to make changes without prior notice
29
C5.1-16-03-v1
2.5.3.1. Operation program
User can set up to twenty operation programs for the
unit. For each program possible to adjust the mode
of operation, day of the week and the time interval.
2.5.3.2. Holidays
Holiday schedule species the time period during
which the unit operates under selected mode. Pos-
sible to set up to ten holidays.
Program 2
Operation mode
COMFORT 1
Weekdays
Mo/Tu/We/Th/Fr/Sa/Su
Start time
00:00
Stop time
24:00
Delete program
Holidays 2
Operation mode
STANDBY
From
12/14
Till
12/26
Delete holiday
Holidays
Holidays 1
Add new holidayAdd new program
Enable
Program 1
Operation program
2.5.4.1. Air handling unit settings
Temperature control
The air handling unit provides for several temperature control modes:
• Supply. The unit supplies air according to the temperature preset by the user.
• Extract. Unit automatically supplies air of such temperature to maintain preset
exhaust air temperature.
• Room. Operation is similar to the mode “exhaust” but temperature is maintai-
ned by the sensor mounted in the room (B8).
• Balance. Supply air temperature maintenance value will be determined auto-
matically from the existing exhaust air temperature, i. e., what the air will be
removed from the premises, and the same will be returned back.
When “Balance” is selected, the temperature setpoint disappears.
Air volume control
Supply and exhaust air volumes control modes have been provided in the unit:
• CAV – constant air volume control mode. The unit will supply and extract a constant air ow which is preset
by the user, irrespective of any changes occurring in the ventilation system;
• VAV – variable air volume control mode. The unit will supply and extract an air ow with regard to the
ventilation needs in different rooms. In case of frequently changing ventilation demands this air volumes
maintenance mode signally reduces unit exploitation costs.
It is possible to use a simplied VAV control function, “single-ow VAV control”. It means that the perfor-
mance of this function requires only a single air ow pressure sensor, which is installed in a variable air duct
system (e. g. in supply air). This variable system is called the master ventilation system, according to which
2.5.4. Settings
This menu is for air handling unit and the user param-
eter setting.
Air handling unit
Personalization
Settings
Functions Settings
Overview Scheduling
Menu
Reset settings
Air handling unit
Temperature control
Flow control
Time/Date
Connectivity
