Chapter 1 Overview
1-7
■
Options
See "Print Controller specification" for details on which printer controllers support each of the options.
●
PostScript3 (PS-343/345)
Installing the optional PostScript3 chip and Compact Flash enables copiers to be used as PostScript3 print-
ers.
●
Expansion Memory (MU-404/405/411)
Increasing the amount of memory enables the print controller to handle larger data files and improves print
performance.
●
Hard Disk (field option)
Installing the optional hard disk for the print controller lets the copier work as a scanner. The scanned data
can be by accessed computers via the network.
Operating Conditions
Card Type : PCMCIA Type1 or Type2
Power supply voltage : 3.3V+/-0.15V (Stand-alone operation)
Current consumption : 500mA max.
Safety approvals : The following certifications must have already been acquired
• UL Recognized Component (NWGQ2)
Standard: UL1950 or UL60950
• C-UL or CSA Recognized Component (NWGQ2)
Standard: CSA c22.2 No.950 or CSA c22.2 No.60950
• TÜV-GS
Standard: EN 60950
Recommended products
The following hard disks have been checked by Konica and found to be compliant.
Caution
Do not install memory other than that specified.
Manufacturer Product name Capacity Remarks
TOSHIBA PAMHD002 2GB
PAMHD005 5GB The area that can actually be used is up to 2 GB.
IBM DSCM-11000 1GB A PC card adaptor is required.
Caution
The system software (VxWorks) used in the print controller can handle disk
capacities up to 2 GB.
When a hard disk larger than 2 GB is connected, the hard disk capacity dis-
played on the copier operation panel or [Config. Data] is 2 GB.
