IP-423 PARTS
Ref.
No.
Part No. Description
Ref
No.
Part No. Description
1 13RN80520 Cooling fan/M a 00Z183041
2 13WJ-9010 Printer control board assembly b 00Z193041
3 450011270 Table knob screw c 00Z163061
4 13FM73191 Auxiliary spring d 00Z183201
5 13WJ-9020 Printer I/O board assembly e 00Z670306
f 00Z610401
