Specifications General
261
Options
Appearance and specifications of this product are subject to change without notice.
General Audio Inputs (Analog)
(Digital)
Audio inputs 1, 2 1/4" TRS balanced
Input Impedance: 10 kΩ
Nominal Level: LINE
+4 dBu (Analog Input Gain = min), –36 dBu (Analog Input Gain = max)
Nominal Level: MIC
–22 dBu (Analog Input Gain = min), –55 dBu (Analog Input Gain = max)
Maximum Level: LINE
+16 dBu (Analog Input Gain = min), –24 dBu (Analog Input Gain = max)
Maximum Level: MIC
–10 dBu (Analog Input Gain = min), –43 dBu (Analog Input Gain = max)
Source Impedance: 600 Ω
Signal to noise ratio: 95 dB (typical)
Dynamic range: 95 dB (typical)
Crosstalk: 95 dB, at 1 kHz (typical)
USB B Format: 24 bit
Sample Rate: 48 kHz
2 channels
Control Inputs DAMPER (half damper supported)
ASSIGNABLE SWITCH, ASSIGNABLE PEDAL
MIDI IN, OUT, THRU
USB USB A (TYPE A) For connection to QWERTY keyboards, MIDI controllers, ethernet adapters,
and storage devices
USB B (TYPE B) MIDI/audio interface
MIDI: 1 (16 channel) input / 1 (16 channel) output
Audio: 2 channel input / 2 channel output
2 USB 2.0 High-Speed ports (supports 480 Mbps)
Drive 60 GB SSD
Power AC Power Supply terminal, (power button)
Dimensions (W x D x H) NAUTILUS-61: 1,062 x 386 x 116 (mm) / 40.88”× 15.19” × 4.57”
NAUTILUS-73: 1,227 x 386 x 116 (mm) / 48.30”× 15.19” × 4.57”
NAUTILUS-88: 1,437 x 387 x 139 (mm) / 56.57”× 15.11” × 5.47”
Weight NAUTILUS-61: 13.0 kg / 28.66 lbs
NAUTILUS-73: 14.6 kg / 32.18 lbs
NAUTILUS-88: 23.1 kg / 50.92 lbs
Power Consumption 40 W
Accessories Power cord, Quick Start Guide
Hardware VOL/EXP PEDAL XVP-20
Foot Controller EXP-2
Damper Pedal DS-1H
Pedal Switch PS-1, PS-3
Other MIDI Cable
